16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01)
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 2
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 3
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 4
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 5
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 6
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 7
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 8
Category

16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01)

Price:

Original price was: ₨720,000.Current price is: ₨612,000.

Category

The HopeTrek ESS-LB16-W01 is a 16.08kWh low-voltage LiFePO₄ battery system with 314Ah capacity, approximately 14.4kWh usable energy and an intelligent Battery Management System. It provides at least 8,000 cycles, up to 200A discharge current, CAN and RS485 communication, and expansion support for up to 16 battery packs in parallel.

Quantity:

[yith_sl_find_in_stores]

Delivery Charges as Per location

House no: 4/3, Street 4, Township, Gondal Chowk, Lahore.

Dispatch Within 24 Hour

Cash On Delivery Available

7 Days Easy Return & Exchange

16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01)
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 2
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 3
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 4
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 5
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 6
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 7
16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01) - Image 8

16.08kWh Low-Voltage LiFePO₄ Battery System (ESS-LB16-W01)

The HopeTrek ESS-LB16-W01 is a 16.08kWh low-voltage LiFePO₄ battery system with 314Ah capacity, approximately 14.4kWh usable energy and an intelligent Battery Management System. It provides at least 8,000 cycles, up to 200A discharge current, CAN and RS485 communication, and expansion support for up to 16 battery packs in parallel.

Availability:  In Stock
👀 people are viewing this product

Original price was: ₨720,000.Current price is: ₨612,000.

Delivery & Service Panel
Delivery
📦
Estimated Delivery 1 - 2 Working Days
💳
Available Payment Method
Service
⏱️
7 Days Free & Easy Return Hassle-Free Returns
🏅
Official Warranty Official Warranty is Available
🔒
Secure Payment Protected Transactions
📦
Estimated Delivery 1 - 2 Working Days

Description

The 16.08kWh lithium battery system is designed for reliable and efficient energy storage, featuring safe LiFePO₄ chemistry, an intelligent Battery Management System (BMS), high-current performance and an extended cycle life of at least 8,000 cycles. With modular expansion, CAN and RS485 communication, LED status indicators and convenient mobility, it provides a practical energy storage solution for compatible inverter systems.

Product Features

Energy Capacity: 16.08 kWh Usable Energy: Approx. 14.4 kWh at 90% DoD
Battery Chemistry: LiFePO₄ Battery Management System: Intelligent BMS
Rated Charge/Discharge Current: 160 A Maximum Discharge Current: 200 A
Cycle Life: At least 8,000 cycles Depth of Discharge: 90%
Parallel Connection: Up to 16 battery packs Communication: CAN & RS485
Indicators: SOC, Running & Alarm Mobility: Integrated Wheels
Support: Adjustable Support Feet Protection Rating: IP20
Installation: Indoor Operating Temperature: -30°C to 55°C
Maximum Installation Altitude: 4,000 m Inverter Compatibility: Approved Compatible Systems
